Unit III Electricity & Magnetism



Static Electricity Intro





I.  Static Electricity - electronic charges flowing in no particular direction. (trapped in a body)



A) Electricity of the Atom

Atoms are
 ordinarily neutral



#p = #e-



n has no charge



p has +1 charge



e- has -1 charge





Charge electron


-1.6 x 10-19 Coulombs
(Reference)











Did you know ....



Benjamin Franklin

National Portrait Gallery, London: NPG 327
Author - Joseph Siffred Duplessis (died 1802)

  • coined the terms positive and negative for electrical charge

  • proved lightning was static electricity

  • invented lightning rod

  • built a static electricity generator








1. Atoms become charged by gaining or losing ...





Electrons





3 Big Rules of Electrostatics

Opposites Attract




Likes Repel



Only Electrons Move

(Protons move, but don't leave nucleus)






Charge plates can deflect an electron









Mg+2   F -1

Mg atom
Lost 2 electrons



F  atom
gained 1 electron

20 p , 18 e-
What's the charge?





+ 2









Why are protons never lost or gained?



Protons are held in the nucleus by the strongest forces in the universe







a) Ion: electrically charged particle:





Charge is unbalanced







 negative charge







#e > #p











positive charge





#p > #e









2. Charged objects lose their charge when grounded. (become neutral)

[ Flash ]



"What is the

bottom prong of

 a plug called?"



"The bottom prong of
a plug called the ground.
It discharges any excess
charge that may develop
in an electrical device"



When grounded:





Negatively charged objects ...





... lose electrons

and become neutral.









Positively charged object ...





... gain electrons

and to become neutral.





Electroscope
